6 Core Gate Motor Cable for Centurion Systems Vantage and Vector, per Metre
6 core gate motor cable sold per metre (quantity = metres) for Centurion Systems Vantage and Vector swing gate motors: 2 thick cores for motor power, 4 thin cores for the position sensor. Manuals under Documents.
- 6 core2 thick + 4 thin
- Motor + sensorPower and position sensor in one cable
- Vantage and VectorCenturion Systems swing gate motors
- 10m maxController to operator, Vantage Smart
-
Alectra Hatfield 648 Jan Shoba Street, HatfieldMon to Fri 07:30 to 17:00, Sat 08:00 to 17:00Get directions
-
Alectra Wonderboom Braam Pretorius Street, WonderboomMon to Sun 08:00 to 16:45Get directions
Choose Pickup at checkout and we message you when your order is ready to collect, usually within 24 hours. You can pay online, or pay at the branch when you collect.
This is 6 core gate motor cable for Centurion Systems Vantage and Vector swing gate motors, sold per metre. It is the cable that runs from the controller to each operator: 2 thick cores carry power to the motor and 4 thin cores serve the position sensor. It suits the Centurion Systems Vantage 400 and the Centurion Systems Vantage 500. The price is per metre and the quantity box is the number of metres. Both Centurion Systems installation manuals are under Documents on this page.
What the 6 cores do
The 2 thick cores feed the motor. The 4 thin cores go to the position sensor, which tells the controller where the gate is: two signal wires, a 5V supply and 0V. That is how the Centurion Systems Vector2 installation manual sets it out, and it is why ordinary 2 core cable cannot do the job.
What the Centurion Systems manuals ask for
The Vantage Smart installation manual calls for a motor cable of at least 2 thicker cores plus 4 thinner multi-stranded cores between the controller and each operator, and gives a maximum of 10m from the controller to the operator. The Vector2 installation manual says to leave a 350mm loop of cable at the operator, and to run the cables in conduit unless underground cable is used. We sell 20mm and 25mm PVC conduit. Read the manual for your motor before the cable goes in; both are under Documents.
How much Centurion Systems Vantage cable to order
Measure the route the cable will take from the controller to each operator and add the 350mm loop at the operator end. A double swing gate has two operators, so measure each run on its own and add them together. On a Vantage Smart system, keep each run within the 10m the manual gives. Type the total number of metres into the quantity box: 12 in the box means 12 metres.
Supply only
Alectra Solutions supplies the cable. Fitting the gate motor and running its cable is the job of your gate motor installer.
Key features
- 6 cores in one cable. 2 thick cores for motor power and 4 thin cores for the position sensor.
- For swing gate motors. Suits Centurion Systems Vantage and Vector swing gate motors.
- The layout the manuals describe. 2 thick plus 4 thin cores between the controller and each operator.
- One run per operator. A double swing gate needs a separate run to each of its two operators.
- Manuals on this page. The Vantage Smart and Vector2 installation manuals are under Documents.
Specifications
| Cable type | 6 core gate motor cable |
|---|---|
| Thick cores | 2, for motor power |
| Thin cores | 4, for the position sensor (two signal wires, 5V supply, 0V) |
| Suits | Centurion Systems Vantage and Vector swing gate motors |
| Run length (Vantage Smart) | Maximum 10m from controller to operator, per the manual |
| Loop at operator (Vector2) | 350mm, per the manual |
| Sold as | Per metre (quantity box = number of metres) |
Not in the box
- Gate motor, controller and position sensor
- Conduit
- Installation (done by your gate motor installer)
Manuals and documents
Questions people ask
It suits Centurion Systems Vantage and Vector swing gate motors. Check the installation manual for your motor, under Documents, before you order.
2 thick cores feed the motor and 4 thin cores go to the position sensor: two signal wires, a 5V supply and 0V.
Measure the route from the controller to each operator, add a 350mm loop at the operator and add up the runs. On Vantage Smart keep each run to 10m or less. Type the total metres in the quantity box.
The Vector2 manual says to run the cables in conduit unless underground cable is used. Plan to run this cable in conduit.
No. The motor needs its 2 thick cores and the position sensor needs its own 4 thin cores, which is why the manuals call for 6.
No. Alectra Solutions supplies the cable and the motors. Installation is done by your gate motor installer.
Need it fitted? Alectra Solutions supplies product only. Ask the branch and we will point you to installers in Pretoria.
