DTS TX5 Octo 5 button gate remote
By DTS

DTS TX5 Octo 5 Button Gate Remote, 8 Functions plus Panic

DTS TX5 Octo gate remote: 5 buttons give 8 functions plus a panic button. Encrypted code hopping on 433.92MHz that cannot be cloned, CR2032 coin cell with a low-battery LED. For DTS receivers and gate motors.

  • 5 buttons8 functions plus panic
  • 433.92MHzFrequency
  • Code hoppingEncrypted, 64 bit
  • CR2032Coin cell battery
R 155.00
Collect at a branch, no charge
  • Alectra Hatfield 648 Jan Shoba Street, HatfieldMon to Fri 07:30 to 17:00, Sat 08:00 to 17:00
    Get directions
  • Alectra Wonderboom Braam Pretorius Street, WonderboomMon to Sun 08:00 to 16:45
    Get directions

Choose Pickup at checkout and we message you when your order is ready to collect.
Pairs well with
DTS Expert 500 Sliding Gate Motor Kit with Anti-Tamper Bracket, 4m Nylon Rack and 2 Remotes
R 5,399.00
DTS Expert Gate Motor + Battery
R 5,099.00
DTS ECO GATE MOTOR KIT BUNDLE
R 5,399.00

The DTS TX5 Octo is the DTS remote that gets nine functions out of five buttons. Buttons 1 to 4 give functions 1 to 4, the red upper-level button opens up functions 5 to 8, and holding the red button gives a ninth, which DTS uses as its panic button. It sends DTS's encrypted code hopping on 433.92MHz, 64 bit with all DTS receivers, and it cannot be cloned. It is the remote for DTS gate motors such as the DTS Expert gate motor full kit.

How 5 buttons give 8 functions plus panic

  • Functions 1 to 4: press button 1, 2, 3 or 4.
  • Functions 5 to 8: press the red upper-level button first (the LED shows green for 2 seconds), then button 1, 2, 3 or 4.
  • Function 9, panic: hold the red button down for more than 2 seconds.

DTS also puts a door lock and unlock function on button 3. In the photo the four function buttons sit in two rows (white, yellow, green and blue) with the red upper-level button on its own below them.

Encrypted code hopping that cannot be cloned

DTS calls its coding encrypted code hopping. With all DTS receivers it runs at 64 bit, and DTS says the remote cannot be cloned. DTS receivers take the TX5 Octo only, so if you have a DTS gate motor, this is the remote to buy.

CR2032 battery and low-battery warning

The remote runs on a CR2032 coin cell. When the LED flashes red, the battery is low and due for a change. It is rated for -10°C to 60°C. DTS gives a 12 month guarantee on the remote; the battery is excluded.

Pairing to your DTS receiver

A new remote must be learned into your DTS receiver before it works. You or your installer do this with the motor or receiver manual; the DTS datasheet is in the documents on this page. Alectra Solutions supplies the remote only. For a new gate, see the DTS Eco gate motor kit or the DTS Expert gate motor with battery.

Courier anywhere in South AfricaR160 for orders up to 10 kg. Heavier orders are priced by weight at checkout. Free courier on orders of R8,000 or more, up to 10 kg.
Collect in Pretoria at no chargeChoose collection at checkout and pick up at Hatfield or Wonderboom.
Genuine stockSupplied through the official South African distributors, with the supplier warranty.
Key features
  • Nine functions from five buttons. Buttons 1 to 4, then red plus 1 to 4 for functions 5 to 8.
  • Panic button. Hold the red button for more than 2 seconds for function 9, DTS's panic button.
  • Encrypted code hopping. 64 bit with all DTS receivers.
  • Cannot be cloned. DTS's coding stops the remote from being copied.
  • Low-battery LED. A flashing red LED tells you the coin cell is low.
  • CR2032 coin cell. A common coin cell battery.
  • Door lock on button 3. DTS puts a door lock and unlock function on button 3.
Specifications
BrandDTS
ModelTX5 Octo
Buttons5 (4 function buttons plus red upper-level button)
Functions8, plus panic as function 9
CodingEncrypted code hopping, 64 bit with all DTS receivers
Frequency433.92MHz
BatteryCR2032 coin cell
Operating temperature-10°C to 60°C
ICASA approvalTA-2016/2849
Sold asSingle remote
Not in the box
  • DTS gate motor and receiver
  • Pairing to your receiver (done by you or your installer)
Manuals and documents
Questions people ask
How do I get functions 5 to 8 on the DTS remote?

Press the red upper-level button first. The LED shows green for 2 seconds. Then press button 1, 2, 3 or 4 for functions 5 to 8.

Which button is the panic button?

Hold the red button down for more than 2 seconds. That sends function 9, which DTS uses as its panic button.

Can the TX5 Octo be copied or cloned?

No. DTS uses encrypted code hopping, 64 bit with all DTS receivers, and says the remote cannot be cloned.

What battery does it take?

A CR2032 coin cell. When the LED flashes red, the battery is low.

Will this remote work with my DTS Expert or Eco gate motor?

It is made for DTS receivers, and DTS receivers take the TX5 Octo only. It has to be learned into the receiver before it works.

Is there a guarantee?

Yes, DTS gives a 12 month guarantee. The battery is excluded.

Need it fitted? Alectra Solutions supplies product only. Ask the branch and we will point you to installers in Pretoria.
