The Centurion Systems D5 Evo Smart is South Africa's most popular sliding gate motor, and has been for several years. It sits in the mid-range of Centurion Systems' lineup, above the entry-level D3 and below the heavy-duty D10. If you're considering automating a standard residential sliding gate, this is almost certainly the motor your installer will recommend.
But is it actually worth buying in 2026? Here's our honest assessment.
Specifications at a Glance
| Specification | D5 Evo Smart |
|---|---|
| Maximum gate weight | 500kg |
| Maximum gate length | ~10 metres |
| Motor type | 24V DC brushless |
| Drive type | Rack and pinion |
| Battery backup | Built-in 12V 7Ah (external 18Ah compatible) |
| App control | Yes (CONNECT.e app) |
| Anti-theft alarm | Yes |
| Obstacle detection | Yes |
| Warranty | 2 years (motor), 5 years (gearbox) |
Performance: What It's Actually Like to Use
Speed and Smoothness
The D5 Evo Smart uses a brushless DC motor, quieter, more efficient, and longer-lasting than brushed motors found in cheaper alternatives. Operation is smooth, with adjustable speed and soft start/stop that prevents jerking.
For a 6 to 8 metre gate, full opening takes approximately 12 to 18 seconds, fast enough for daily use without feeling slow.
Load Shedding Performance
This is where the D5 Evo Smart earns its popularity. The built-in 7Ah battery provides approximately 50 to 80 complete gate cycles on a full charge. For most households, this is 2 to 4 days of normal use without mains power.
For households experiencing heavy load shedding (Stage 4 to 6), an external 18Ah battery extends backup to 150 to 200 cycles, effectively unlimited for most families. The D5 Evo Smart supports this external battery connection natively.
App Control (CONNECT.e)
The CONNECT.e app works reliably and is well-designed. You can open or close the gate from anywhere with an internet connection. Useful features include:
- Gate status (open/closed)
- Notifications when the gate is operated
- Guest access codes
- Usage history
Setup takes about 10 minutes and is straightforward.
Anti-Theft Features
The D5 Evo Smart includes an anti-theft bracket that locks the motor to the gate rail, making it significantly harder to remove without tools. It also has a built-in alarm that sounds if someone attempts to force the gate while the motor is engaged.
Installation
The D5 Evo Smart is professionally installed by Centurion Systems-approved installers. Typical installation takes 2 to 4 hours and includes:
- Motor mounting and rack installation
- 2 remotes programmed
- Safety reversing test
- Battery backup test
DIY installation is possible for experienced DIYers, but warranty may be affected if not installed by a registered installer.
Value for Money
Supply cost: R4,500 to R6,500 (motor only) Installed cost: R6,500 to R10,000 (including installation, remotes, anti-theft bracket)
Compared to budget alternatives at R2,500 to R4,000 installed, the D5 Evo Smart costs more, but the build quality, reliability, load shedding performance, and Centurion Systems' South African support network justify the premium for most homeowners.
Verdict: Is the D5 Evo Smart Worth It?
Yes, for most South African homes, the Centurion Systems D5 Evo Smart is the best gate motor available at its price point.
The combination of brushless motor reliability, excellent load shedding backup, app control, and Centurion Systems' widespread installer support makes it the obvious recommendation for standard residential sliding gates. The 5-year gearbox warranty gives genuine peace of mind.
The only reason to choose differently: if your gate weighs over 500kg (spec the D10 instead) or if budget is very tight (consider the D3 for basic automation without smart features).
